ASTM A516 Grade 70 Plate Supplier in Bhopal
Chiranjiv Steel Centre supplies and stocks ASTM A516 Grade 70 plates for pressure vessel, boiler and heavy engineering shops in Bhopal, the capital of Madhya Pradesh, since the state was formed in 1956. The industrial belts east and south of the city work to the same grade, and we supply them out of held stock. Approximately 2000 tons of plate stands in our two Navi Mumbai yards at Taloja and Kalamboli. Kalamboli is approximately 781 km from Bhopal by road and Taloja approximately 776 km, with loads running north through Nashik and Dhule before turning east above Indore. An order placed against ready stock leaves the yard in 2 to 3 working days. We settle the transportation cost with the transporter when the vehicle is booked, rather than quoting a delivery date read off a map.
The stocked band covers 3 mm to 20 mm thickness, in widths of 1250 mm and 1500 mm, at lengths of 5000 mm and 6300 mm. Heavier material is arranged on an order basis, up to 100 mm. Plate to 20 mm leaves the yard as-rolled, while anything above 40 mm is supplied normalised against order, and the delivery condition appears on the certificate either way. Cut-to-size work comes off those same stock plates, and custom dimensions can be arranged where a drawing calls for them. Dual certification covers ASTM A516 Gr 70 and ASME SA 516 Gr 70, with an EN 10204 3.1 Mill Test Certificate raised against each plate.
On this Page
- ASTM A516 Grade 70 Plate Supplier in Bhopal
- Our supply position for Madhya Pradesh
- Why Bhopal fabricators order against held stock
- Sizes held for cutting and dispatch
- A516 / SA 516 Grade 70 datasheet
- Which documents come with the plates
- A516 Gr 70 plate price for Bhopal delivery
- Where A516 Gr 70 plate is used in Bhopal
- Dispatch and packing to Bhopal
- Industrial belts served around Bhopal
- Why Chiranjiv Steel Centre
- FAQs
A516 Gr 70 Plate: Our Supply Position for Madhya Pradesh
| Supply Parameter | Our Position |
|---|---|
| Thickness from stock | 3 mm to 20 mm |
| Thickness against order | Up to 100 mm |
| Width | 1250 mm and 1500 mm |
| Length | 5000 mm and 6300 mm |
| Supply condition | As-rolled to 20 mm from ready stock; normalised above 40 mm, against order |
| Grade certification | Dual certified ASTM A516 Gr 70 / ASME SA 516 Gr 70 |
| Cutting | Cut to size from stock plates, worked against your list or drawing |
| Dispatch | 2 to 3 working days on ready-stock orders |
Why Bhopal Fabricators Order Against Held Stock
Fabricators in Bhopal gain a lot of benefits by choosing ASME SA 516 Gr 70 plates from us. The same has been displayed in the table given below.
| Where a Bhopal order stalls | What buying from stock alters |
|---|---|
| A mill rolling slot puts the plate weeks away while the vessel stands half built. | Approximately 2000 tons is already on the ground at Taloja and Kalamboli. A confirmed order loads in 2 to 3 working days. |
| The drawing names one delivery condition and the yard books another. | You fix the condition when the order is placed, and it prints on the certificate. |
| A certificate query surfaces once the load has covered approximately 781 km. | Your inspection desk holds the MTC while the plate is still standing at the yard. |
| Freight gets paid on steel that ends up in the offcut rack. | We cut to your list first, so the tonnage on the vehicle is tonnage that enters the job. |
| One header job will not fill a truck on its own. | Bhopal consignments move as part loads, and three jobs share a vehicle on this corridor. |
| A tank contract needs steel in stages rather than in one delivery. | Project lots stay in Navi Mumbai and release truck by truck against the site call-off. |
| An out-of-state purchase complicates the tax working. | A Maharashtra delivery carries CGST and SGST. A Madhya Pradesh consignment is an inter-state supply and carries IGST as one line. |
Sizes Held for Cutting and Dispatch
| Size | Size | Size | Size | Size |
|---|---|---|---|---|
| 3 × 1250 × 6300 | 5 × 1500 × 5000 | 6 × 1250 × 5000 | 8 × 1500 × 6300 | 10 × 1250 × 5000 |
| 10 × 1500 × 6300 | 12 × 1500 × 5000 | 12 × 1250 × 6300 | 14 × 1500 × 6300 | 16 × 1250 × 5000 |
| 16 × 1500 × 6300 | 18 × 1500 × 5000 | 20 × 1250 × 6300 | 20 × 1500 × 5000 | 20 × 1500 × 6300 |
ASTM A516 / ASME SA 516 Grade 70 Datasheet
Which Documents Come With the Plates?
Six items make up a standard dispatch file, and each one exists to get the load past an incoming inspection without an argument.
- Mill Test Certificate to EN 10204 3.1, raised plate by plate rather than against a batch
- Both designations on one document: ASTM A516 Gr 70 alongside ASME SA 516 Gr 70
- Heat number and plate number hard stamped into the plate face, so identity survives the cutting table
- Cast analysis, tensile results and the recorded delivery condition, all on that same certificate
- Pre-dispatch inspection at Taloja or Kalamboli, by your engineer or an agency you nominate
- HIC certification to NACE TM0284, ultrasonic examination and third party inspection, arranged against order
Sour-service qualification under NACE MR0175 or MR0103 sits outside our supply programme. Where an enquiry carries that clause, we flag it at quotation instead of after dispatch.
A516 Gr 70 Plate Price for Bhopal Delivery
ASTM A516 Gr 70 plate in Bhopal is quoted from approximately ₹65-95 per kg ex-yard Taloja or Kalamboli for boiler quality material. Road freight into Madhya Pradesh is priced as its own line, because the rate per tonne falls once a vehicle fills. An offer holds for the validity printed on it, since plate rates track mill and scrap movement week to week.
Six Inputs Behind the Quoted Rate
- Plate size. Thickness above 20 mm, or width beyond 1500 mm, carries a size extra over the standard stock envelope.
- Tonnage. A bulk release prices under a cut-piece requirement of the same grade.
- Delivery condition. Normalising and stress relieving add a processing cycle, and that cycle sits inside the rate.
- Supplementary testing. A HIC package to NACE TM0284 lifts the figure and stretches the lead time.
- Certificate type. EN 10204 3.1 is standard. Type 3.2 needs third-party endorsement and is charged on its own.
- Cutting scope. Profile work and edge preparation are priced from the drawing, never off a rate card.
For the current pricing of SA 516 Gr 70 plates in Bhopal, reach out to us.
Looking for ASTM A516 Grade 70 Plates?
Where in Bhopal is ASTM A516 Gr 70 Plate Used?
Bhopal is an equipment fabrication centre rather than a refinery city, and its plate demand follows the shape of that. Heavy electrical manufacturing on the eastern side of the city built up a vendor base of pressure parts and tankage shops from the 1960s onward. Process industry at Mandideep accounts for a second slice. Agro processing across Sehore, Raisen and Vidisha districts, together with project work on the southern road corridor, takes the rest. Four groups absorb most of the Grade 70 tonnage we move into the region, and each of them buys on a different rhythm.
Heavy Electrical Equipment Vendors in Govindpura
Govindpura Industrial Area holds the oldest concentration of engineering job shops in Bhopal, much of it built around the heavy electrical equipment works on the city’s eastern edge. Shops here roll drum courses, weld header stubs and fabricate the tanks, casings and utility vessels that go alongside generating plant. Most of that work falls between 8 mm and 20 mm and comes straight off the shelf. Heavier sections to 100 mm are supplied normalised against order.
Chemical and Pharmaceutical Vessel Shops at Mandideep
Mandideep Industrial Area sits immediately south of the city in Raisen district and carries a few hundred units, weighted towards chemicals, pharmaceuticals, packaging and light engineering. Reactors, jacketed vessels, receivers, condenser shells and effluent holding tanks in that belt run on this grade. Buyers here place modest repeat lots against a batch-change schedule rather than a construction programme, which keeps their order sizes small and their delivery windows tight. Where wet hydrogen sulphide is present in the stream, they specify HIC-tested plate, supplied against order with a certificate to NACE TM0284.
Tank and Agro Processing Fabricators at Bagroda and Acharpura
Job shops at Bagroda and Acharpura build bulk storage tanks, silos, dryer bodies, evaporator sections and utility vessels for grain handling, dairy, solvent extraction and food plants across central Madhya Pradesh. Shell courses and annular plate for that work come out of the stocked band.
Project Fabricators on the Obaidullaganj and Tamot Belt
Contractors working the Obaidullaganj and Tamot corridor south of the city adapt to a construction programme, and that changes how they buy. They confirm a project tonnage in one order, then call it forward in stages as erection advances. We hold the balance at Taloja or Kalamboli and release it truck by truck against the site call-off, so a fabrication yard never carries steel it can’t lay down yet. Storage vessels, surge drums and pressure equipment for water treatment and industrial park utilities make up most of that tonnage.
Dispatch and Packing on a Madhya Pradesh Delivery
A run of approximately 781 km puts three or four handling points between our yard and a Bhopal fabrication bay. Packing and marking are set to survive all of them.
Packing: strapped bundles as standard, with wooden cases or crates where thickness and quantity justify them
Marking: heat number and specification hard stamped on every plate, tying the steel to its certificate through fabrication
Inspection: your own engineer, or an agency you appoint, is welcome at the yard before loading
Terms of supply: ex yard Kalamboli or Taloja, or delivered into your works in Bhopal
Service area: Bhopal city, the Mandideep and Obaidullaganj corridor, Sehore, Raisen and Vidisha districts, and the wider Madhya Pradesh market
Dispatch and transit: standard sizes load within 2 to 3 working days of confirmation, cut sizes take a further 2 to 3 working days, and the road leg is confirmed at booking
Industrial Belts Served Around Bhopal
- Govindpura Industrial Area, Bhopal
- Mandideep Industrial Area, Raisen district
- Bagroda Industrial Area and its extension sectors
- Acharpura Industrial Area
- Berasia and the belt north of the city
- Obaidullaganj and the Bhopal to Hoshangabad road corridor
- Tamot and the Plastic Park sectors, Raisen district
- Raisen town and the Sanchi road belt
- Badiyakhedi Industrial Area, Sehore
- Ashta, Sehore district
- Pilukhedi Industrial Area, Rajgarh district
- The Vidisha district industrial belt
Why Chiranjiv Steel Centre for A516 Gr 70 Plate in Bhopal?
Five points separate a direct purchase from a re-sold one:
- Trading since 2000. Chiranjiv Steel Centre has spent over two decades in the plate trade, and our enquiry desk answers on pressure part requirements rather than on rate alone.
- Approximately 2000 tons in the yard. A holding band of 3 mm to 20 mm keeps a rolling programme off your critical path.
- Two yards, one loading point. Taloja and Kalamboli let a Bhopal consignment go out whole instead of split across two dispatches.
- Documentation that clears a gate. EN 10204 3.1 certification with full heat and plate traceability, sent ahead of the vehicle.
- Sizes that nest. Widths of 1250 mm and 1500 mm against lengths of 5000 mm and 6300 mm trim the offcut on common shell developments.
Send the grade, thickness, plate size and tonnage, and we’ll come back with the stock position and a rate.
