ASTM A516 Grade 70 Plate Supplier in Bangalore
Chiranjiv Steel Centre stocks and supplies ASTM A516 Grade 70 plates to Bangalore, a city whose heavy engineering base was laid by the public sector machine tool, aircraft and electrical works set up here through the 1940s and 1950s. Fabrication shops across those belts still build pressure vessels, boiler components, heat exchangers and storage equipment in this grade. Our holding runs to approximately 2000 tons across two yards at Taloja and Kalamboli in Navi Mumbai, so a released order pulls steel that has already been rolled, tested and certified.
Kalamboli is approximately 947 km from Bangalore by road, and the vehicle runs south along the NH-48 spine through Pune, Satara, Belagavi and Tumakuru. Loading against ready stock takes 2 to 3 working days from order confirmation. The transporter fixes running time at booking, not the kilometre figure. Everything in the 3 mm to 20 mm ready band leaves us as-rolled. At 40 mm and under the standard treats as-rolled as normal supply, and normalised plate in that band is bought against order. Above 40 mm the standard requires normalising, and that material comes on an order basis. Whichever condition applies is written into the certificate.
Widths of 1250 mm and 1500 mm run at lengths of 5000 mm and 6300 mm, across a ready-stock band of 3 mm to 20 mm thickness. Anything above 20 mm, out to a maximum of 100 mm, is arranged on order. Each plate holds dual certification to ASTM A516 Gr 70 and ASME SA 516 Gr 70, with an EN 10204 3.1 Mill Test Certificate raised against it.
On this Page
Ready Stock Position Behind a Bangalore Order
| Stock Detail | Bangalore Supply Position |
|---|---|
| Ready stock quantity | Approximately 2000 tons |
| Thickness in stock | 3 mm to 20 mm |
| Thickness on order | Up to 100 mm |
| Plate width | 1250 mm and 1500 mm |
| Plate length | 5000 mm and 6300 mm |
| Supply condition | As-rolled across the full 3 mm to 20 mm ready stock. Normalised at 40 mm and under against order. Normalised above 40 mm, against order |
| Certification | Dual certified ASTM A516 Gr 70 / ASME SA 516 Gr 70 |
| Warehouse location | Taloja and Kalamboli, Navi Mumbai |
What Slows a Bangalore Plate Order, and What Stock Supply Fixes
| Where the order stalls | What held stock changes |
|---|---|
| A mill rolling programme pushes the delivery date out by weeks. Fabrication stops at the shell course. | Approximately 2000 tons is already on the floor at Taloja and Kalamboli. Release to loading takes 2 to 3 working days. |
| The drawing specifies normalised. As-rolled reaches the shop. | You fix the condition when the order is placed, and it goes on to the certificate. |
| A documentation query opens up at your gate, approximately 947 km from the yard. | Your inspection team reads the MTC while the plate is still in our yard. |
| A full plate is bought to cut one shell course. The balance sits as an offcut. | We cut to your sizes first, so the freight bill covers steel that enters the job. |
| A part quantity looks uneconomic to move over a run this long. | Loads consolidate on the Bengaluru route, and several orders share one vehicle. |
| An out-of-state purchase complicates the input credit. | Maharashtra to Karnataka is inter-state. IGST appears as a single creditable line. |
Sizes Held Against Bangalore Enquiries
| Size | Size | Size | Size | Size |
|---|---|---|---|---|
| 6 × 2000 × 12000 | 8 × 2500 × 12000 | 10 × 2000 × 12000 | 10 × 2500 × 12000 | 10 × 2500 × 6000 |
| 12 × 2000 × 12000 | 12 × 2500 × 12000 | 14 × 2000 × 12000 | 14 × 2000 × 5400 | 14 × 2500 × 12000 |
| 16 × 2000 × 12000 | 16 × 2500 × 12000 | 18 × 2500 × 12000 | 20 × 2500 × 12000 | 22 × 2000 × 11500 |
| 25 × 2500 × 12000 | 25 × 2500 × 9000 | 32 × 2500 × 6000 | 32 × 2500 × 3000 | 36 × 2500 × 6000 |
| 40 × 2500 × 6000 | 40 × 2500 × 7000 | 75 × 2500 × 4100 | 90 × 2500 × 6800 | 90 × 1500 × 2700 |
ASTM A516 / ASME SA 516 Grade 70 Datasheet
Which Documents Travel With a Bangalore Consignment?
Documentation reaches you before the vehicle does, and an incoming inspection desk in Bangalore asks for six things:
- A plate-specific Mill Test Certificate under EN 10204 3.1.
- Both the ASTM A516 Gr 70 and the ASME SA 516 Gr 70 designation printed on that one certificate.
- Hard stamping on the plate, so heat number and plate number stay readable through fabrication.
- Ladle analysis, tensile figures and delivery condition on the certificate.
- Pre-despatch inspection at Taloja or Kalamboli, by your own engineer or a nominated agency.
- HIC testing to NACE TM0284 with its certificate, arranged on request. Sour-service qualification to NACE MR0175 sits outside our supply programme. Raise that requirement before a purchase order is cut.
Material SA 516 70 Plate Price in Bangalore
ASTM A 516 Gr.70 plate in Bangalore works out from approximately ₹65-95 per kg on boiler quality material, taken ex-yard at Taloja or Kalamboli. Freight to Bangalore is priced as its own line, since cost per tonne drops once a vehicle fills. An offer holds only for the validity shown on it, since plate rates track mill and scrap movement.
Six Things That Move a Bangalore Quotation
The rate against your enquiry moves on six variables:
- Thickness, width and length: anything over 20 mm, or wider than 1500 mm, attracts a size extra above standard stock dimensions.
- Order quantity: a multi-tonne full-plate order is rated below cut pieces.
- Supply condition: normalised material carries an extra processing cycle at the mill, so it always sits above as-rolled on the rate.
- Test scope: Charpy V-notch impact testing to Supplementary Requirement S5 is quoted against the test temperature and absorbed energy on your order, and at 40 mm and under it also brings normalised supply unless you specify otherwise. HIC testing under NACE/AMPP TM0284 lengthens the lead time and lifts the rate. Both are settled at enquiry stage, not after the order is released.
- Certification level: the standard here is EN 10204 3.1, and it travels with every plate. Where a project specification calls for a Type 3.2 inspection certificate, raise it at enquiry stage so the route and the cost can be settled before the order is placed.
- Cut-to-size work: cut pieces, blanks and circles for dished ends and tube sheets are rated separately against the drawing you send.
Contact us for current pricing of ASME SA 516 Gr 70 Plates in Bangalore.
Looking for ASTM A516 Grade 70 Plates?
Which Bangalore Industrialists Buy SA516 Gr 70 Plate?
Bangalore is not a refinery or petrochemical city, and demand here doesn’t behave the way it does in Jamnagar or Vadodara. Consumption is OEM-led and shop-led: whoever builds the equipment buys the plate, not the plant that will run it, and much of what leaves these yards is installed elsewhere in South India. Most of our Grade 70 tonnage into Karnataka goes to four groups: pressure vessel and process equipment fabricators, boiler auxiliary and power equipment builders, storage and industrial gas tankage shops, and project contractors buying against a programme. Each buys on a different pattern. An enquiry written as A516M Grade 485 asks for the same steel; 485 is the minimum tensile strength in MPa, and Grade 70 states the same requirement in ksi.
Pressure Vessel and Process Equipment Fabricators
Peenya Industrial Area covers more than 1,200 acres and several thousand units, and the engineering shops inside it form the largest single concentration of plate fabrication in the city. Air receivers, jacketed reactors, autoclaves and columns leave these yards for pharmaceutical, chemical and food processing clients across Karnataka. Shell courses sit inside the 3 mm to 20 mm band we hold, while dished end blanks and the heavier nozzle reinforcement plates that go with them are arranged against order.
Boiler Auxiliary and Power Equipment Builders
Package boilers, economiser casings, deaerators, feed water tanks and header assemblies come out of the shops at Dabaspet, Nelamangala and Doddaballapur, mostly for sugar, textile processing and captive power work across South India. Heat number, plate number and the matching EN 10204 Type 3.1 certificate arrive with the steel, so the QA file closes on the day of receipt. Boilers registered under the Indian Boiler Regulations bring a separate requirement: IBR approval and documentation fall outside what an EN 10204 Type 3.1 supply covers, so raise that point before the order is released.
Storage Vessel and Industrial Gas Tankage Shops
Order sizes in this group run small and frequent rather than as single project lots. Medium-sized fabricators across Bommasandra, Jigani and Attibele build receivers, buffer vessels, ammonia and LPG storage shells, and the casings and support structures around industrial gas equipment. Most of that work falls between 8 mm and 20 mm, the heart of our ready stock.
Project Contractors and Aerospace-Adjacent Fabrication
Contractors handling process plant and utility packages out of Bidadi, Harohalli, Hoskote and the Whitefield belt order in project lots rather than single plates. Deliveries are staggered to a fabrication programme, so their tonnage waits at Taloja or Kalamboli and goes out truck by truck as the shop calls for it. The aerospace and defence supply chain around Devanahalli and Peenya works to a second pattern: small tightly specified quantities, a heavy documentation load, and an order that arrives as a drawing rather than a size list.
Packing, Marking and Road Movement to Bangalore
A run of this length is harder on packing than a short local delivery. Plates travel in bundles or wooden cases, stamped so identity survives every handling point between Navi Mumbai and your yard. Terms for packing, marking, inspection and delivery follow.
PackagingBundles as standard, with wooden cases or crates where the thickness and quantity justify them
Marking and traceabilityHeat number and specification are hard stamped into each plate, so material ties back to its certificate at any stage
Third party inspectionBuyer and agency inspection are both accommodated, and both close before the vehicle leaves
Shipping termsEx yard at Taloja or Kalamboli, or delivered into your Bangalore gate
Service areaBangalore city, the Tumakuru Road and Hosur Road belts, Bengaluru Rural district and the rest of Karnataka
Despatch and transitStandard sizes off ready stock load inside 2 to 3 working days, and cut pieces leave on the same schedule; NH-48 running time is fixed by the transporter at booking
Bangalore Areas We Deliver Into
- Peenya Industrial Area, Phases I to IV
- Rajajinagar Industrial Estate and Yeshwanthpur
- Dasarahalli, Jalahalli and the Tumakuru Road belt
- Nelamangala, Dabaspet and Doddaballapur
- Bommasandra and Jigani Industrial Areas
- Attibele, Anekal and the Hosur Road corridor
- Hoskote and the Old Madras Road corridor
- Whitefield, Mahadevapura and Bidadi
- Harohalli and the Kanakapura Road belt
- Devanahalli and the Bengaluru Rural district
Why Bangalore Buyers Place the Order With Chiranjiv Steel Centre
Bangalore fabricators give five reasons for coming back:
- Established in 2000. Two decades trading steel, the last half-decade on pressure vessel plate.
- Approximately 2000 tons held. A ready band of 3 mm to 20 mm keeps mill rolling schedules out of your delivery date.
- Two yards feeding one load. Taloja and Kalamboli consolidate a Bangalore consignment instead of splitting it across despatches.
- Documentation that clears inspection. EN 10204 3.1 certificates with heat number traceability, so nothing stalls at a gate approximately 947 km from the yard.
- Sizes that cut economically. Widths of 1250 mm and 1500 mm against lengths of 5000 mm and 6300 mm keep offcut down on common shell developments.
Send the grade, thickness, plate size and tonnage, and the quotation will be sent back on the same working day.
